Pneumatic component is used with other pneumatic components for assembly pneumatic schematic and to do various experiments in pneumatics. The component structure is robust with T screw fixations and big hand wheels for easy screwing component to the aluminium plate. We used only high-quality industrial originals components
Technical characteristics:
✓ ISO cylinder
✓ Piston diameter 25 mm
✓ Stoke 100 mm
✓ Operation pressure 0.5bar-10bar
✓ Piston speed 50-1500 mm/s
✓ Proof pressure 15 bar
✓ Stroke tolerance 0/+1.4 mm
✓ 5 mm board with schematic drawing
✓ 2 big fixing bolts with 2 T bolts
