Description
Technical characteristics:
✓ Mounting box (1 pc)
-4 mm safety connections
-sabotage contact
✓ Transformer (1 pc)
-inserted into installation box
✓ Accumulator (1 pc)
-voltage 12 V
-capacity 7 Ah
✓ Central unit (1 pc)
-8 zones with the possibility of expanding up to 32 zones
-PGM output 2+2
-15 pcs . pluggable keyboards
-1 controlled audio siren output
-1 controlled output of the power supply circuit
-1 controlled telephone li ne
-possibility to call 2 security services
-possibility to call 5 private numbers
✓ Keyboard (1 pc)
-32 zones with LED indication
-dual domain status monitoring
-malfunction s indication button
-3 variations of panic messages
✓ Keyboard with touch screen (1 pc)
-8 PGM control
-7“ screen 800×840 pixels
-possibility to display photos on the screen
-internal temperature sensor
-screen control mode
✓ Motion sensor (1 pc)
-dual element sensor
✓ Conventional smoke sensor (1 pc)
-2 LED indication
-current consumption 8mA 10V DC, 25mA 30V DC
✓ Magnetic contact (1 pc)
-5 contacts
✓ Internal siren (1 pc)
-sound level 1m 113 dB
-two tones
✓ Outdoor siren (1 pc)
-battery 12 V, 1.2 Ah
-sound level 1m 11 5 dB
✓ Leads (1 set)
-flexible cable 6 x 0.22 mm² 100 m.
-flexible cable 1×0.5mm2 red 100 m.
-flexible cable 1×0.5mm2 blue 100 m.
-flexible cable 1×0.75mm2 b lack 100 m.
-flexible cable 1×0.75mm2 brown 100 m.
-flexible cable 1×0.75mm2 green yellow 100 m.
✓ Storage box (1 pc
-with grooves
