Cross-section of the 6-section injection pump model

This cross-section model of a 6-section injection pump provides an in-depth view of its internal mechanisms and fuel injection process. It features key components such as the plunger, plunger sleeve, slider, camshaft, pressure valve, and a centrifugal regulator for precise fuel delivery control. The model also includes two different types of injectors, fuel filters, and a fuel pump, making it an excellent educational tool for studying diesel injection systems.
