Description
Technical characteristics:
✓ Fire alarm central unit (1 pc)
-4 zones with the possibility of expanding up to 20 zones
– 4 remote control repeater panels are supported
-easily programmable
-According to EN12094 1 standard
-LCD screen
-30 fire detectors are connected for each zone
-configurable input and output contact
-controlled output for telephone dialling activation
-alarm and error memory
-front panel notes are in Lithuanian
-12V/7Ah batteries are inserted (2 pcs)
✓ Batteries (2 pcs)
-Voltage 12 V
-capacity 7 Ah
✓ Conventional smoke sensors (2 pcs)
-Safety class IP43
-protection zone with a radius of 15 m and a height of 11 m
-operating cycle current 120 μA
✓ Conventional rising temp. sensors (2 pcs)
-Safety class IP43
-protection zone with a radius of 10 m and a height of 8 m
– operating cycle current 55 μA
✓ Fire alarm button (1 pc)
-key reset
-safety class IP42
-LED indicator
✓ Outdoor siren with flash (1 pc)
-current used 40 mA
-sound level 114 dB
-32 ringtones
-41 Hz flash frequencies
-adjustable sound level 20 dB
-safety class IP44
✓ Aerosol (1 pc)
-adapted for smoke detector testing
-capacity 250 ml.
✓ Cables (1 set)
-fire protection cable 2×0.5 mm 2 100 m.
-flexible cable 1×0.5mm2 red 100 m.
-flexible cable 1×0.5mm2 blue 100 m.
-flexible cable 1×0.75mm2 black 100 m.
-flexible cable 1×0.75mm2 brown 100 m.
-flexible cable 1×0.75mm2 green yellow 10 0 m.
✓ Terminals for distribution box
-2*0.5 2.5mm2 50 pc s
-3*0.5 2.5mm2 50 pc s
-4*0.5 2.5mm2 50 pc s
-5*0.5 2.5mm2 50 pc s
✓ Storage box (1 pc
-with grooves for placing equipment
