KNX RF+ wireless switching actuator 2 channels

KNX RF+ wireless switching actuator 2 channels. Intelligent KNX smart home system designed to form a real smart home electrical system. This stand offers different modules using them students learn how to properly connect components to each other, accordingly program and test them.
Photo is for reference, actual product might be different.

SKU: ESKXK1-1 Category:

Description

Technical characteristics:
KNX wireless switching actuator 2 channels (1 pc.):
✓ 150 m operating distance
✓ 230 V voltage
✓ Max. lamp load: 1.9 kW incandescent bulb, 0.8 kW halogen bulb, 0.5 kW fluorescent bulb
✓ Software: ETS 5
✓ Life span 1 million mechanical cycles
✓ Safety class IP20
✓ 8 scenes across the channel
✓ Central switching function with block functions
✓ NC and NO contact operations
✓ Time functions
✓ Integrated electric socket
✓ Stand housing thickness 5 mm
✓ Stand housing with laser engraved schematic
✓ Shock-resistant cover, tilted in an ergonomically favourable angle of 15°, for placement on a horizontal working surface
✓ Suitable for installation into a carrying case for storage and safe transport
✓ KNX component structure is visual that students would see real component
✓ Stand component description (component marking) can be done in any language
